Self Checkout Kiosk Pro with Stand + Payments

RRP: £3299.00

Saving 52%

Our price: £1599 EX VAT

Colour

Shipping

£39.99
  (Next working day dispatch)

Quantity


Our interactive Self Service Kiosks are designed to help hospitality venues of all sizes drive sales, reduce operational costs, and improve speed of service.

Allow your customers to order and pay themselves, while the kiosk's full integration with Grafterr Hospitality software puts you in full control of the experience they see - it can seamlessly synchronise your existing food menus, send orders directly to the kitchen, instantly process card payments, print receipts, and even promote and up-sell additional items, if desired.

Additionally, the built-in extensive customisation options allow you to adjust the images, designs and even button colours to match your existing branding.

Secure payments with Grafterr Pay

The included Wisepad 3 card terminal allows the kiosk to accept credit and debit card payments at competitive rates thanks to the integration with Grafterr Pay - our fast, secure payment solution.



Product features:

  • Self service kiosk with a 27 inch touchscreen
  • Full integration with Grafterr Hospitality software lets you gain powerful insights into your business and customers
  • Secure credit/debit card processing with included WisePad 3 wireless card reader
  • Offers a compact, space-saving design perfect for smaller venues
  • Allows customers to order and pay themselves using our simple ordering and payment tech
  • Fully customisable checkout experience allows customers to choose between eat-in or take away orders, cash or card payments, apply gift vouchers and more
  • Allows for automatic upselling of additional items, increasing average order size by up to 20%
  • Features an integrated receipt printer and voucher scanner
  • Floor standing model - stainless steel floor stand is included



Included in the box:

  • 27" touchscreen self checkout kiosk with latest software
  • Wisepad 3 wireless card reader
  • Stainless steel floor stand
  • Metal bracket for wall mounting

Speakers: : 10W*2 Active loudspeaker
Minimum Resolution: : 4 mil Code39
2-D: : PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, MicroQR, Aztec, Hanxin, etc
1-D: : UPC, EAN, Code128, Code 39, Code 93, Code11, Matrix 2 of 5, Interleaved 2 of 5, Codabar, MSI Plessey, GS1 DataBar, China Postal, Korean Postal, etc.
Interfaces Supported: : USB, RS232
Motion Tolerances: : up to 600 cm per second
Print Contrast : 25% minimum reflective difference
Field of view: : 50° (H) x 35° (V)
Roll /Pitch /Yaw : 360°, ±65°, ±60°
Scanner light Source: : Illumination: 617nm RED LED
Scanner Current: : 500mA (Operating)
Scanner Voltage: : 5 VDC
Driver: : Windows98/2000/NT/XP/Vista/Win7/Win8/Linux
Power Supply: : DC24V, 2A
Emulation: : ESC/POS
Auto Cutter Method : with automatic paper cutting function
Paper Width: : 80mm
Printing Speed: : 170mm/s
Printing Resolution: : 8 dots/mm, 576 dots/line
Operation Systems: : Android 7.1
Printing Method: : Thermal Line dot printing
Image Format Support: : Support BMP JPEG PNG GIF
Video Format Support: : Support wmv avi flv rm rmvb mpeg ts mp4 etc
Time - Power off : Support
RTC (Real -Time Clock) : Support
Ethernet: : 1@ 100M/1000M Ethernet
WiFi BT: : Built in WIFI BT4.0(optional) support dual frequency WIFI, dual antenna
3G/4G (Optional): : Built-in WCDMA,EVDO,4GFull Netcom ,Support voice calls
HDMI Output: : 1@,support 1080P@60Hz 4kx2k@60Hz output
USB Interface: : 6 insert pin, 2 standard USB interface
ROM: : 16GB
Serial Port: : 5 channels serial port (3*232;1*TTL;1*485)
RAM: : 4G
CPU: : Rockchip RK3399 higest64 bits CPU Main Frequency 2.0GHz 1.Big,Little architecture;Dual-core Cortex-A72 + Quad CortexA53;2.Built-in low power sonsumption Mcu Cortex-Mo GPU:Quad Cortex-Mali-T860MP4;Android 7.1
Touch Screen Transparency: : 87±2%
Touch Screen Model: : 10- point capacitive Touch screen
Viewing Angle: : 178/178
Respond Time: : 8ms
Resolution: : 1920*1080
Brightness: : 300cd/m2
Contrast: : 1000:1
Screen size : 27 Inch
Operating Temperature: : 0 ~ 40 (32 ~ 104 )
Storage Temperature: : 10 ~ 95% @ 40
Power Input : AC 100-240V
Dimensions (W x H x D) : 109*59*26cm
Weight: : 33kg
Installation: : Wall mounted/ fix on stand
Frequently asked questions

Is software included?

While the checkout comes with our software preinstalled, you’ll need a monthly software subscription to activate it. Our packages start at just £49 p/m for a single kiosk.

How do I install the checkout in my business?

All of our self checkouts are plug & play and come with a handy installation guide. To install your self checkout, you’ll need two mains sockets for power nearby, and we always recommend using a LAN connection, but you can use WiFi if you prefer.

What warranty do I get?

You’ll get a 1 year warranty with all your hardware. If your kiosk breaks, we’ll send you a brand new replacement within 24 hours!

Does this kiosk process card payments?

Yes. This Self Checkout bundle includes a WisePad 3 wireless card reader, so you can start taking credit & debit card payments right away.
